Vivotek MA9322-EHTVL 20MP, Adjustable Views, 3.7~7.7mm, 30M IR, WDR Pro, SNV
Made in:
Technology:
Brand
Original price was: $2,700.00.$2,025.00Current price is: $2,025.00.
- H.265 Compression Technology
- 4x 5MP Independent Sensors, Adjustable Views
- 30 fps (2688×1920) per Sensor
- WDR Pro (120 dB) for Optimal Image Quality in High Contrast Environments
- SNV (Supreme Night Visibility) for Low Light Conditions
- Built-in IR Illuminators, Effective up to 30 Meters Radius
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Built-in Microphone
High Quality Unlimited Coverage
Featuring four independent 5MP CMOS Sensors with IR illuminators, the MA9322-EHTVL network camera can provide the most flexibility in surveillance monitoring. Each sensor utilizes a 3.7 to 7.7 mm motorized focus lens and 3-axis design along a circular track to enable full 360° coverage. The MA9322-EHTVL is equipped with a removable IR-cut filter and WDR Pro technology, enabling the camera to maintain optimal image quality and unparalleled visibility in high contrast lighting environments.
360° Extreme Low Light Visibility
By adding IR illumination up to 30 meters, no matter day or night, light or dark, it always provides complete video security. Further, in addition to SNV technology, areas of low light visibility are no longer an issue either.
Comprehensive Video Coverage from a Single Mount Point
The MA9322-EHTVL captures every angle for comprehensive video coverage from a single IP address, helping to reduce the amount of cameras needed and saving on installation time and costs.
System Information
- Model
- MA9322-EHTVL
- CPU
- Multimedia SoC (System-on-Chip)
- Flash
- 1 GB
- RAM
- 4 GB
Camera Features
- Image Sensor
- 1/2.7″ Progressive CMOS
- Max. Resolution
- 2688×1920 (5MP) x 4
- Lens Type
- Motorized, Vari-Focal, Remote Focus
- Focal Length
- f = 3.7 ~ 7.7 mm
- Aperture
- F1.9 ~ F2.9
- Iris Type
- Fixed-iris
- Field of View
- 88.6° ~ 40.1° (Horizontal)
61.2° ~ 28.6° (Vertical)
115.5° ~ 49.5° (Diagonal)
- Shutter Time
- 1/5 sec. to 1/32,000 sec.
- WDR Technology
- WDR Pro
- Day/Night
- Yes
- Removable IR-cut Filter
- Yes
- IR Illuminators
- Built-in IR illuminators, effective up to 30 meters with Smart IR
- Minimum Illumination
- 0.035 lux @ F1.9 (Color)
0.005 lux @ F1.9 (B/W)
0 lux with IR Illuminators on
- Tilt Range
- 0° ~ 105° each lens
- Rotation Range
- ±90° each lens
- Pan/Tilt/Zoom Functionalities
- ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
- Storage
- Seamless Recording to MicroSD/SDHC/SDXC card and recording to network-attached storage (NAS)
- Built-in Installation Aids
- Remote Focus, Remote Zoom
Video
- Video Compression
- H.265, H.264, MJPEG
- Maximum Frame Rate
- 12 fps @ (2688×1920) x 4
30 fps @ (2560×1440) x 4
- Maximum Streams
- 2 simultaneous streams* per channel; max total 13 profiles
* Stream 1: 2688×1920, 2560×1920, 2160×1536, 2048×1536, 1680×1200, 1600×1200, 1344×960, 1280×960, 672×480, 640×480
* Stream 2: 1280×960, 672×480, 640×480
- S/N Ratio
- 60.4 dB
- Dynamic Range
- 120 dB
- Video Streaming
- Adjustable resolution, quality and constant bit rate control
- Image Settings
- General settings: video title and time stamp overlay, video orientation (flip, mirror), day/night settings; Illuminators: illuminators, anti-overexposure; Image settings: white balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, 3DNR, HLM; Exposure: BLC, HLC, exposure control (exposure level, iris adjustment, exposure time, gain control), AE speed adjustment, WDR; Privacy mask; Scheduled profile settings
Audio
- Audio Capability
- Two-way Audio (full duplex)
- Audio Compression
- G.711, G.726
- Audio Interface
- Built-in microphone
External microphone input*
External line output*
* Requires AO-006 cable
- Effective Range
- 5 meters
Network
- Users
- Live viewing for up to 20 clients
- Security
- Access list, digest authentication, HTTPS, IEEE 802.1x, Password protection, user access log, user account management
- Protocols
- 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
- Interface
- 10 Base-T/100 Base-TX/1000 Base-T Ethernet (RJ-45)
* It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
- ONVIF
- –
Solution Integration
- Video Motion Detection
- Five-window video motion detection
Alarm and Event
- Event Trigger
- Audio detection*, camera tampering detection, digital input*, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, system boot
* Requires AO-006 cable
- Event Action
- Event notification via audio clip*, digital output, email, HTTP, FTP, NAS server, SD card
File upload via email, HTTP, FTP, NAS server, SD card
* Requires AO-006 cable
System Requirements
- Operating System
- Microsoft Windows 10/8/7
Mac 10.12 (Chrome only)
- Web Browser
- Chrome 58.0 or above
Internet Explorer 10/11
- Other Players
- VLC: 1.1.11 or above
Included Accessories
- Packing Contents
- Quick installation guide, alignment sticker, desiccant bag, screw driver, screws pack
DORI (EN 62676-4 Standard)
- Detect (25PPM/ 8PPF)
- Wide: 74.0 m (242.8 ft)
Tele: 153.9 m (505.0 ft)
- Observe (63PPM/ 19PPF)
- Wide: 29.3 m (96.1 ft)
Tele: 61.1 m (200.4 ft)
- Recognize (125PPM/ 38PPF)
- Wide: 14.8 m (48.6 ft)
Tele: 30.8 m (101.0 ft)
- Identify (250PPM/ 76PPF)
- Wide: 7.4 m (24.3 ft)
Tele: 15.4 m (50.5 ft)
| Weight | 50.00 lbs |
|---|---|
