Hikvision DC01 04CH 4K Decoder

• Support network camera, NVR, and other devices to serve as network signal source.
• Support 4K (3840 × 2160@30 Hz) UHD video output via HDMI 1.4 output interface.
• Support two audio output methods: embedded HDMI audio output and external audio output.
• Adopt frame synchronization technology to ensure complete synchronization of images from all output interfaces, complete pictures, smooth playback, and without lag, frame loss, tearing or splicing
• Support H.264 and H.265 encoding of input boards, and sub-stream and main stream encoding; the default encoding format is H.264.
• Support network cameras, NVR and other network sources decoding of output boards, sub-stream and main stream decoding including H.264, H.265, Smart264, Smart265, MJPEG, HIK264 and main encapsulation formats such as PS, RTP, TS, ES.
• Support encrypted stream, multi-channel stream, and smart stream decoding, stream editing and switching, and auto switching to the sub stream when the divided window quantity reaches the upper limit.
• Support up to 16 video decoding channels and simultaneously decoding of 16-ch 2 MP video to the video wall.
• Support decoding streams of multiple resolution no more than 32 MP.
• Support rotate mode of front-end cameras decoding and up to 2560 × 1440 decoding output.

Decoder, supports Output: 1*HDMI/1*BNC, Input: Network RJ45 only support 3840*2160@30HZ, decoding capacity. Support 1-ch 32 MP/24 MP/2-ch 12 MP/14-ch 8 MP/5-ch 6 MP/9-ch 4 MP/16-ch 1080p and below real-time decoding (4 outputs in a group, sharing decoding capabilities) Support H.264, H.265, SmartH.264, SmartH.265, MJPEG Decoding Format Support up to 32MP Resolution
